| Supported operating systems |
Windows® 10(1), Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008(2) |
| Scanner type |
ADF (Automatic Document Feeder) + Manual Feed |
| Scanning modes |
Simplex / Duplex, Color / Grayscale / Monochrome |
| Image sensor type |
Color CCD (Charge-coupled device) x 2 (front x 1, back x 1) |
| Light source |
White LED array(3) |
| Multifeed detection |
Ultrasonic multi-feed detection sensor x 3, Paper detection sensor |
| Document size |
Maximum |
A3 Portrait (297 x 420 mm or 11.7 x 16.5 in.)
Double letter (279.4 x 431.8 mm or 11 x 17 in.) |
| Minimum |
A8 Portrait (52 x 74 mm or 2 x 3 in.) |
Long paper scanning
(Maximum)(4) |
up to 3,048 mm (120in.) |
| Paper weight (Thickness) |
Less than A5 size: 0.050 to 0.25 mm (41 to 209 g/m², or 11 to 56 lb)
A4 to A5 size: 0.025 to 0.25 mm (20 to 209 g/m², or 5.4 to 56 lb)
Over A4: 0.050 to 0.25 mm (41 to 209 g/m², or 11 to 56 lb) |
Scanning speed
(A4 (Letter) Landscape)(5) |
Color(6) |
Simplex: 100 (100) ppm @ 200/300 dpi
Duplex: 200 (199) ipm @ 200/300 dpi |
| Grayscale(6) |
| Monochrome |
Scanning speed
(A4 (Letter) Portrait)(5) |
Color(6) |
Simplex: 85 (87) ppm @ 200/300 dpi
Duplex: 170 (174) ipm @ 200/300 dpi |
| Grayscale(5) |
| Monochrome |
| ADF Capacity(7) |
500 sheets (A4/Letter: 80 g/m² or 20 lb) |
| Background colors |
White / Black (Selectable) |
| Optical resolution |
600 dpi |
| Expected Daily Volume |
91,000 sheets |
Output
resolution(8) |
Color (24-bit) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)(9) |
| Grayscale (8-bit) |
| Monochrome (1-bit) |
| Output format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Internal video processing |
1,024 levels (10-bit) |
| Interface |
USB2.0 |
| Connector shape |
B type |
| Image processing functions |
Auto color detection, Automatic page size detection, De-skew, Automatic orientation, Upper lower separation, Multi-image output, Blank page skip, Error diffusion, Dither, Dropout color (R, G, B, None, White, Specified, Saturation), Image emphasis, Simplified DTC, Advanced DTC, iDTC, sRGB |
| Power requirements |
AC 100 to 240 V ±10 % |
| Power consumption |
Operating: 200 W or less
Sleep mode: 3.2 W or less
Auto Standby (OFF) mode: Less than 0.5 W |
| Operating environment |
Temperature: 15 to 35 °C (59 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing) |
| Dimensions: Width x Depth x Height(10) |
460 x 430 x 310 mm (18.1 x 16.9 x 12.2 in.)
Installation space: 860 x 1,630 x 350 mm (33.8 x 64.1 x 13.7 in.) |
| Weight |
32 kg or less |
| Included software / drivers |
PaperStream IP driver (TWAIN/TWAIN x64/ISIS), WIA Driver(11), PaperStream Capture, 2D Barcode for PaperStream(12), Software Operation Panel, Error Recovery Guide, Scanner Central Admin |
| Environmental compliance |
ENERGY STAR® / RoHS |
| Included items |
AC cable, USB cable, Setup DVD-ROM |
| Options |
Post Imprinter (Front-side) and Post Imprinter (Back-side), PaperStream Capture Pro |
