| Printing Method |
Direct Thermal & Thermal Transfer |
| Printing Resolution |
203 dpi (8 dots/mm) |
| Printing Speed |
Max 6ips |
| Printing Length |
Max. 100”(2540mm) |
| Printing Width |
Max 4.25"(108mm) |
| Memory |
128MB SDRAM, 128MB Flash ROM |
| CPU Type |
32 bit RISC microprocessor |
| Sensors |
Reflective sensor |
| Operation Interface |
LED indicator x 2, Button(Feed) x 1 |
| Communication Interface |
OS-214EX Pro: Ethernet, USB 2.0 device, RS-232, USB 2.0 host OS-200 Pro: USB 2.0 device |
| Fonts |
Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily. Support scalable font. GB 18030 Standard (Chinese coded character set) support. |
| 1D Barcodes |
UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirecional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked |
| 2D Barcodes |
QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode, Aztec |
| Graphics |
PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI |
| Emulation |
PPLA, PPLB, PPLZ |
| Software-label Editing |
BarTender® from Seagull Scientific. Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf), iLabelPrint+ |
| Software-utility |
Printer Tool, Font Utility |
| Driver tools |
Argox Seagull Driver (Win7/Win8/Win10/Win11), Argox Linux Printer Driver, Argox macOS Printer Driver, Argox RPi Printer Driver |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper |
| Media |
Max. width: 4.3” (110mm). Min. width: 0.8” (20mm). Thickness: 0.0025”~0.01” (0.0635mm~0.254mm) Max roll capacity (OD): 5” (127mm) Core size: 0.5” (12.7mm) Max roll capacity (OD): 5” (127mm) Core size: 1” (25.4mm) Max roll capacity (OD): 5” (127mm) Core size: 1.5” (38.1mm) |
| Ribbon |
Ribbon Width: 1”~4”(25.4mm~102mm), Ribbon roll – max OD: 1.45”(37mm), Ribbon Length: Max 92m. Core size – ID: 0.5”(12.7mm) with notch, Wax, Wax/Resin, Resin (Outside and Inside Ribbon) |
| Printer Dimensions |
W 182.5mm x H 173.5mm x D 282mm |
| Printer Weight |
3.4 lbs (1.54kgs) |
| Power Source |
Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 2.4A |
| Operation Environment |
Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) |
| Agency Listing |
CE, FCC, cULus, CCC, BIS, BSMI, RoHS |
| Optional Items |
Cutter, External media stand, Label rewinder |
| Attention |
*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. |
