| Scanner Type |
ADF (Automatic Document Feeder) / Manual Feed, Duplex |
Scanning Speed (A4 Portrait)
(Color/Grayscale/Monochrome) |
Simplex |
50 ppm (200/300 dpi) |
| Duplex |
100 ipm (200/300 dpi) |
| Image Sensor Type |
CIS x 2 (front x 1, back x 1) |
| Light Source |
RGB LED x 2 (front x 1, back x 1) |
| Optical Resolution |
600 dpi |
Output Resolution
(Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) |
| Output Format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors |
White / Black (selectable) |
| Document Size |
Maximum |
215.9 x 355.6 mm (8.5 x 14 in.) |
| Minimum |
48 x 50 mm (1.9 x 2 in.) |
| Long Page Scanning |
6,096 mm (240 in.) |
| Paper Weight (Thickness) |
Paper |
20 to 465 g/m² (5.3 to 124 lb) |
| Booklet |
Less than 7 mm (0.276 in.) |
| Plastic Card |
1.4 mm (0.055 in.) or less |
| ADF Capacity |
100 sheets (A4 80 g/m² or Letter 20 lb) |
| Expected Daily Volume |
8,000 sheets |
| Multifeed Detection |
Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection |
Image monitoring |
| Interface |
USB |
USB 3.2 Gen1x1 / USB 2.0 / USB 1.1 |
| Ethernet |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Power Requirements |
AC 100V - 240V 50/60 Hz |
| Power Consumption |
Operating Mode |
21 W or less / 17 W (Eco mode) |
| Sleep Mode |
LAN: 2.0 W or less
USB: 1.4 W or less |
| Auto Standby (Off) Mode |
0.2 W or less |
| Operating Environment |
Temperature |
5 to 35 °C (41 to 95 °F) |
| Relative Humidity |
15 to 80% (Non-condensing) |
| Environmental Compliance |
ENERGY STAR®, RoHS |
| Dimensions (W x D x H) |
300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in.) |
| Weight |
4 kg (8.8 lb) |
| Supported Operating System |
Windows® 11, Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, macOS, Linux (Ubuntu) |
| Software / Drivers |
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver, Image Scanner Driver for macOS (ICA), Image Scanner Driver for Linux (SANE), PaperStream Capture, PaperStream ClickScan, PaperStream NX Manager, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™, Scanner Central Admin |
| Image Processing Functions |
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold |
| Included Items |
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM |
