INTEL ULTRA 5 245K 5.2GHz LGA1851 Fansız BOX İşlemci

CPU Specifications

Total Cores  : 14

# of Performance-cores : 6

# of Efficient-cores : 8

Total Threads  :14

Max Turbo Frequency  :5.2 GHz

Performance-core Max Turbo Frequency  :5.2 GHz

Efficient-core Max Turbo Frequency  : 4.6 GHz

Performance-core Base Frequency  :4.2 GHz

Efficient-core Base Frequency  :3.6 GHz

Cache  :24 MB Intel® Smart Cache

Total L2 Cache :26 MB

Processor Base Power  :125 W

Maximum Turbo Power  :159 W

Intel® Deep Learning Boost (Intel® DL Boost) on CPU  : Yes

AI Software Frameworks Supported by CPU : OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

CPU Lithography : TSMC N3B

Supplemental Information

Marketing Status : Launched

Launch Date  : Q4'24

Embedded Options Available  : No

Use Conditions  : PC/Client/Tablet, Workstation

Memory Specifications

Max Memory Size (dependent on memory type)  : 256 GB

Memory Types  : Up to DDR5 6400 MT/s

Maximum Memory Speed : 6400 MHz

Max # of Memory Channels : 2

ECC Memory Supported ^‡  : Yes

GPU Specifications

GPU Name : Intel® Graphics

Graphics Base Frequency  : 300 MHz

Graphics Max Dynamic Frequency  : 1.9 GHz

GPU Peak TOPS (Int8)  : 8

Graphics Output  :DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b

X^e-cores : 4

Max Resolution (HDMI)^‡  : 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL)

Max Resolution (DP)‡  : 8K @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡  : 4K @ 60Hz

DirectX* Support  : 12

OpenGL* Support  : 4.5

OpenCL* Support  : 3

Intel® Quick Sync Video  : Yes

# of Displays Supported ^{‡ :} 4

Device ID : 0x7D67

Intel® Deep Learning Boost (Intel® DL Boost) on GPU  : Yes

NPU Specifications

NPU Name^{‡ :} Intel® AI Boost

NPU Peak TOPS (Int8) : 13

Sparsity Support  : Yes

Windows Studio Effects Support : Yes

AI Software Frameworks Supported by NPU : OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

Direct Media Interface (DMI) Revision : 4

Max # of DMI Lanes : 8

Intel® Thunderbolt™ 4  : Yes

Scalability : 1S Only

PCI Express Revision  : 5.0 and 4.0

PCI Express Configurations ^‡  : Up to 1x16+2x4, 2x8+2x4,1x8+4x4

Max # of PCI Express Lanes  : 24

Package Specifications

Sockets Supported : FCLGA1851

Thermal Solution Specification  : PCG 2020A

Max Operating Temperature  : 105 °C

Advanced Technologies

Intel® Gaussian & Neural Accelerator  : 3.5

Intel® Thread Director  : Yes

Intel® Speed Shift Technology  : Yes

Intel® Turbo Boost Technology ^‡  :2.0

Intel® 64 ^‡ : Yes

Instruction Set : 64-bit

Instruction Set Extensions  : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States  : Yes

Enhanced Intel SpeedStep® Technology  :Yes

Thermal Monitoring Technologies  : Yes

Intel® Volume Management Device (VMD) : Yes

Security & Reliability

Intel vPro® Eligibility ^‡  : Intel vPro® Enterprise

Intel® Threat Detection Technology (TDT) : Yes

Intel® Active Management Technology (AMT) ^‡ : Yes

Intel® Standard Manageability (ISM) ^‡  :Yes

Intel® Remote Platform Erase (RPE) ^{‡ :} Yes

Intel® One-Click Recovery ^{‡ :} Yes

Intel® Hardware Shield Eligibility ^‡  :Yes

Intel® Secure Key  : Yes

Intel® Control-Flow Enforcement Technology :Yes

Intel® Total Memory Encryption - Multi Key : Yes

Intel® AES New Instructions  :Yes

Intel® Trusted Execution Technology ^‡  : Yes

Execute Disable Bit ^‡  : Yes

Intel® OS Guard : Yes

Intel® Boot Guard  : Yes

Mode-based Execute Control (MBEC)  : Yes

Intel® Stable IT Platform Program (SIPP)  : Yes

Intel® Virtualization Technology with Redirect Protection (VT-rp) ^{‡ :} Yes

Intel® Virtualization Technology (VT-x) ^‡  :Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ^‡  :Yes

Intel® VT-x with Extended Page Tables (EPT) ^‡ : Yes

EAN Numarası: 5032037282086
