| PERFORMANCE |
| Processor |
Intel® Core™ i7-12700T, 12C (8P + 4E) / 20T, Max Turbo up to 4.7GHz, P-core 1.4 / 4.6GHz, E-core 1.0 / 3.4GHz, 25MB
|
| Graphics |
Integrated Intel® UHD Graphics 770
|
| Chipset |
Intel® Q670 Chipset
|
| Memory |
1x 16GB SO-DIMM DDR4-3200
|
| Memory Slots |
Two DDR4 SO-DIMM slots, dual-channel capable
|
| Max Memory |
Up to 64GB DDR4-3200
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Support |
Up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 SSD up to 2TB
|
| Card Reader |
No card reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC256VB codec
|
| Speakers |
2Wx1
|
| Power Supply |
135W 89% Adapter
|
| Keyboard |
USB Traditional Keyboard, Black, Turkish
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color |
Black
|
| Stand |
None
|
| Adapter Cage |
None
|
| Toolless Chassis Screw |
Toolless Chassis Screw
|
| Dust Filter |
Dust Filter
|
| Mounting |
1x VESA Mount
|
| IO Box |
No IO box
|
| Form Factor |
Tiny (1L)
|
| Dimensions (WxDxH) |
179 x 182.9 x 36.5 mm with rubber feet (7.05 x 7.2 x 1.44 inches with rubber feet)
|
| Weight |
Around 1.25 kg (2.76 lbs)
|
| CONNECTIVITY |
| Ethernet |
Integrated 100/1000M
|
| WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 11ax 2x2 + BT5.1
|
| Front Ports |
- 1x USB-C® 3.2 Gen 1 (support data transfer and [email protected] charging)
- 1x USB 3.2 Gen 2
- 1x USB 3.2 Gen 2 (Always On and [email protected] charging)
- 1x headphone / microphone combo jack (3.5mm)
|
| Optional Front Ports (configured) |
None
|
| Rear Ports |
- 1x USB 2.0
- 1x USB 3.2 Gen 1
- 2x USB 3.2 Gen 2
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4
- 1x Ethernet (RJ-45)
|
| Optional Rear Ports (configured) |
|
| Monitor Cable |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified
|
| Fingerprint Reader |
No fingerprint reader
|
| Physical Locks |
Kensington® Security Slot™, 3 x 7 mm
|
| Kensington Cable Lock |
None
|
| Chassis Intrusion Switch |
Chassis Intrusion Switch
|
| MANAGEABILITY |
| System Management |
Non-vPro®
|
| SERVICE |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
None
|
| CERTIFICATIONS |
| Green Certifications |
- ErP Lot 3 and Lot 7
- RoHS compliant
- TCO Certified 9.0
|
| Other Certifications |
TÜV Rheinland® Low Noise
|
| Mil-Spec Test |
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation)
|
| SOFTWARE |
| Operating System |
None
|
| Bundled Software |
None
|
