Intel Core i7-10700 (8C / 16T, 2.9 / 4.8GHz, 16MB)

Integrated Intel UHD Graphics 630

B560

1x 8GB UDIMM DDR4-2666

Two DDR4 UDIMM slots, dual-channel capable

Up to 64GB DDR4-2933

256GB SSD M.2 2242 PCIe 3.0x4 NVMe

None

Up to two drives, 1x 3.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB

3-in-1 Card Reader

9.0mm DVD±RW

High Definition (HD) Audio, Realtek ALC623-CG codec or ALC897Q codec

2Wx1

260W 85% Power Adapter

USB Calliope Keyboard, Black, Turkish

USB Calliope Mouse, Black

• Two M.2 slots (one for WLAN, one for SSD)
• One PCIe 3.0 x16
• One PCIe 3.0 x1

Chassis: Black Bezel: Silver

None

No stand

Tower (13.6L)

145 x 278 x 340 mm (5.7 x 10.94 x 13.39 inches)

4.8 kg (10.6 lbs)

Integrated 100/1000M

None

• 1x headphone / microphone combo jack (3.5mm)
• 2x USB 3.2 Gen 2
• 2x USB 3.2 Gen 1
• 1x microphone (3.5mm)

1x card reader

• 1x VGA
• 1x Ethernet (RJ-45)
• 1x HDMI 2.0
• 1x serial (9-pin)
• 1x line-in (3.5mm)
• 4x USB 2.0
• 1x DisplayPort 1.4

None

None

Firmware TPM 2.0 integrated in chipset

No fingerprint reader

• Kensington Security Slot
• Padlock Loop

None

Chassis Intrusion Switch

None

1-year, Depot

2Y Keep Your Drive Add On (5PS0K26191), 2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in (5WS0D80980)

• ENERGY STAR 8.0
• EPEAT Silver
• REACH
• WEEE
• RoHS compliant

TÜV Rheinland Low Noise

None

None

None
